DUAL FUNCTION Building Materials

Energy Savings and Photovoltaic Power Generation

Turn Your Building Into a Vertical Power Generator.

KANEKA® ENERGY MANAGEMENT SOLUTIONS’ Thin film Silicon and Hetero-Junction “enabling” technologies – Building Integrated Photovoltaic (BIPV) energy solutions by application.

Cool Roof and Bi-Facial Technology
Functional Building Glass - IGU's
Functional Building Glass - Skylights
Functional Building Glass - Facades

Building Integrated Photovoltaics (BIPV) has the capability to drive these values in the building envelope.

1
Thermal and Acoustical Insulation
2
UV & IR Filtering
3
Daylighting
4
Visible light transmittance (VLT) with energy savings and Energy Generation
5
Form and Function

Driving Value with Building
Integrated Photovoltaics

Standard Laminate

Indicative values only. Actual values may vary according to testing protocols.
Specifications

Transparent PV Glass Thin Film Silicon (TFS)

Transparent PV Glass High Efficiency (HE)

Major Specifications


Return on Investment —Value Streams

Low-e transparent photovoltaic glass in laminate or 2 or 3 IGU form factor

Learn More
1
HVAC Reduction up to 45%
2
Daylighting control
3
Avoided costs – Traditional glass, louver systems, window blinds, etc.
4
Energy Production from transparent PV glass.
5
Battery storage and utility rate arbitrage potentials.
6
Feed-in tariffs, subsidy and/or tax credit programs

Retrofit (Demand Reduction by Transparency)

Chart

IGU & PV Energy Savings - New Construction

Chart

IGU & PV Energy Savings Retrofit

Chart
Disclaimer: Calculated values are based on numerical simulations performed by Institut für Bauklimatik Dresden. For the simulation BIM HVACTool Version 1.8, EnergyPlus Version 8 and NANDRAD Version 1.4 were used. Climate was defined by data from DWD and IWEC. The simulated building has a volume of 11,640m³. 40% of the facade surface is covered by windows.

Path to Realize Lowest Costs and Highest ROI

1
Design with standard size,1200x998mm, as building block to larger sizes vs. customization.
2
Optimal mix of BIPV and Standard IGU construction.
3
Overall IGU glass size dimensions I.E. 2x2, 2x3, 3x3 in standard size PV building block.
4
Optimal IGU construction techniques.

Customization Options Low-e Transparent PV Glass

Size and appearance can be customized.

  • Custom Sizes up to 3602×2996 (10.79m2)
  • Custom Laser scribing techniques to create “bird friendly designs” or mimic fritted glass designs
